Type:
General Rubber Machinery
Type Of General Rubber Machinery:
Material Processing Machine
Product Description
Characteristic:
1. Injecting rubber after the moulding being blocked, high moulding pressure in inner cavity of the mould, high density construction of products, precised size with less scurf.
2. High speed open/close molds, high production efficiency, low blocking speed, protect mold.
3. Automatic in/out mold and ejector device, low labor strength.
4. Optional normal valve or proportional valve, matching-advanced oil way, reduce energy consumption.
5. The electric system adopt PLC programming control, which is easy to be operated.
Model
XZB-630
XZB-1000B
XZB-1000A
XZB-1600
XZB-2000
XZB-2500
Mold-locking force(KN)
630
1000
1000
1600
2000
2500
Injection pressure(MPA)
90
90
125
110
110
120
Material tank size(mm)
φ70×205
φ80×220
φ80×255
φ90×275
φ90×300
φ110×330
Block stroke(mm)
300
300
300
300
300
400
nject and press stroke(mm)
360
360
380
450
480
550
Thermo-plate size(mm)
Zhongxin yi mo
450×480
450×480
520×540
580×600
600×600
700×750
houyimo
420×480
420×480
500×540
530×600
550×600
680×750
Max.distance of thermo-plate(mm)
300
300
300
300
300
400
Motor power(kw)
4
6.2
6.2
6.2
7
7
Qingdao Shengxinze Industry&Trade Co., Ltd. is a comprehensive enterprise which engaged in manufacturing, import &export business fields, With almost 10 years experience in rubber machinery equipment export. We got the great prestige and the status in the profession. Relying on first-class service, strict management, our company established a long-term strategic cooperation relations with many rubber machinery factory through the way of joint venture. We has formed the seriation product mix, can undertake each kind of rubber production production line.
The main product of our company: Internal mixer, Two roll Mixing mill, extruding equipments, calendar equipments, Cutting machine, cooling equipment, Vulcanizing equipment, and Reclaimed rubber production line, rubber sheet extrusion line, Motorcycle&bicycle Tube &Tires production line, Conveyor Belt production line, V belt production line, rubber recap equipment and so on. Besides, we also can base on clients' requirement to manufacture and design non-standard rubber machinery.
With the rapid development of our company, Qingdao Sea King industrial Limited was founded. The company has established good commercial relationship with many companies in China by joint venture holding. Products include Rubber Machine, Raw Rubber Material Rubber Products and so on.
During these years, our company has good working relationship with many rubber machinery factory under our strong foundation, restricted management, good service and reputation. Our business scope and quantity are enhancing.
We strictly follow the policy"to satisfy our clients' need with quality work, advanced technology, optimized design solution and excellent service
